| Name | Length, mm | Width, mm | Height, mm | LED lifetime, h | Output, lm | Power, W | Efficacy, lm/W | CRI (Ra) | CCT, K | Weight, kg | UGR index |
| Bora Z LED 1×5550 G634 T840 L90W HSB | 1606-2446 | 75 | 80 | 100000/L80B10 | 5523 | 30.0 | 184 | 80+ | 4000 | 4.4 | ≤22 |
| Bora Z LED 1×6600 G635 T840 L90W HSB | 1606-2446 | 75 | 80 | 100000/L80B10 | 6567 | 35.9 | 183 | 80+ | 4000 | 4.4 | ≤22 |
| Bora Z LED 1×7600 G636 T840 L90W HSB | 1606-2446 | 75 | 80 | 100000/L80B10 | 7554 | 41.6 | 182 | 80+ | 4000 | 4.4 | ≤22 |
| Bora Z LED 1×6950 G637 T840 L90W HSB | 1906-2746 | 75 | 80 | 100000/L80B10 | 6904 | 36.7 | 188 | 80+ | 4000 | 4.6 | ≤22 |
| Bora Z LED 1×8250 G638 T840 L90W HSB | 1906-2746 | 75 | 80 | 100000/L80B10 | 8209 | 44.4 | 185 | 80+ | 4000 | 4.6 | ≤22 |
| Bora Z LED 1×9450 G639 T840 L90W HSB | 1906-2746 | 75 | 80 | 100000/L80B10 | 9442 | 51.5 | 183 | 80+ | 4000 | 4.6 | ≤22 |
| Bora Z LED 1×11050 G640 T840 L90W HSB | 2746-3586 | 75 | 80 | 100000/L80B10 | 11046 | 58.1 | 190 | 80+ | 4000 | 5.0 | ≤22 |
| Bora Z LED 1×13150 G641 T840 L90W HSB | 2746-3586 | 75 | 80 | 100000/L80B10 | 13134 | 70.3 | 187 | 80+ | 4000 | 5.0 | ≤22 |
| Bora Z LED 1×15150 G642 T840 L90W HSB | 2746-3586 | 75 | 80 | 100000/L80B10 | 15108 | 82.4 | 183 | 80+ | 4000 | 5.0 | ≤22 |
| Bora Z LED 1×13850 G643 T840 L90W HSB | 3260-4100 | 75 | 80 | 100000/L80B10 | 13808 | 72.7 | 190 | 80+ | 4000 | 5.4 | ≤22 |
| Bora Z LED 1×16450 G644 T840 L90W HSB | 3260-4100 | 75 | 80 | 100000/L80B10 | 16418 | 87.0 | 189 | 80+ | 4000 | 5.4 | ≤22 |
| Bora Z LED 1×18900 G645 T840 L90W HSB | 3260-4100 | 75 | 80 | 100000/L80B10 | 18884 | 101.9 | 185 | 80+ | 4000 | 5.4 | ≤22 |
Available options:
T830 – Colour temperature 3000K, CRI 80+
T840 – Colour temperature 4000K, CRI 80+
T930 – Colour temperature 3000K, CRI 90+
T940 – Colour temperature 4000K, CRI 90+
L30 – Optics with 30º beam angle, narrow
L40x75 – Optics with 40×75º beam angle, high rack
L75 – Optics with 75º beam angle, standard
L75W – Optics with 75º beam angle, wide
L90W — Optics with 90º beam angle, wide
L1A18 – Optics with asymmetric beam
L2A25 – Optics with double asymmetric beam
DALI – Driver with DALI interface and switch-control dimming
*note – minimum dimming level for models: G640, G641, G642, G643, G644, G645 is 1 %. For other models – 10 %
BLT – Integrated wireless control unit and driver for lighting control via mobile device (via Bluetooth), with integrated DALI PS
KRBLT – Integrated wireless control unit and driver for lighting control via mobile device (KR system app), on/off
KRBLT DALI – Integrated wireless control unit and driver for lighting control via mobile device (KR system app), DALI with integrated PS
EM3 – Emergency version 3 hours
EM3A – Emergency version equipped with an autonomous testing system, 3 hours
EM3D – Emergency version 3 hours with DALI interface
*note – Operating temperature range for Luminaires with EM option, ºC: 0…+35
L1 – Driver connected to L1 line
L2 – Driver connected to L2 line
L3 – Driver connected to L3 line
2G – Strain relief for power supply cable, 2 pcs
HSB – Adjustable hanger support brackets for luminaire installation across cable trays. Each end extends 180-600 mm
