| Name | Length, mm | Width, mm | Height, mm | LED lifetime, h | Output, lm | Power, W | Efficacy, lm/W | CRI (Ra) | CCT, K | Weight, kg |
| Caelum A LED1x1250 G514 T840 OP | 380 | 135 | 135 | 100000/L80B10 | 1226 | 10.2 | 120 | 80+ | 4000 | 3.0 |
| Caelum A LED1x1550 G515 T840 OP | 380 | 135 | 135 | 100000/L80B10 | 1548 | 12.8 | 121 | 80+ | 4000 | 3.0 |
| Caelum A LED1x1700 G516 T840 OP | 660 | 135 | 135 | 100000/L80B10 | 1685 | 13.8 | 122 | 80+ | 4000 | 3.5 |
| Caelum A LED1x2350 G517 T840 OP | 660 | 135 | 135 | 100000/L80B10 | 2334 | 18.8 | 124 | 80+ | 4000 | 3.5 |
| Caelum A LED1x2900 G518 T840 OP | 660 | 135 | 135 | 100000/L80B10 | 2899 | 21.8 | 133 | 80+ | 4000 | 3.5 |
| Caelum A LED1x2550 G519 T840 OP | 940 | 135 | 135 | 100000/L80B10 | 2528 | 20.1 | 126 | 80+ | 4000 | 5.5 |
| Caelum A LED1x3550 G520 T840 OP | 940 | 135 | 135 | 100000/L80B10 | 3502 | 27.6 | 127 | 80+ | 4000 | 5.5 |
| Caelum A LED1x4250 G521 T840 OP | 940 | 135 | 135 | 100000/L80B10 | 4214 | 32.5 | 130 | 80+ | 4000 | 5.5 |
| Caelum A LED1x3150 G522 T840 OP | 1220 | 135 | 135 | 100000/L80B10 | 3113 | 24.6 | 127 | 80+ | 4000 | 7.4 |
| Caelum A LED1x4700 G523 T840 OP | 1220 | 135 | 135 | 100000/L80B10 | 4668 | 37.2 | 125 | 80+ | 4000 | 7.4 |
| Caelum A LED1x5650 G524 T840 OP | 1220 | 135 | 135 | 100000/L80B10 | 5619 | 43.2 | 130 | 80+ | 4000 | 7.4 |
| Caelum A LED1x3900 G525 T840 OP | 1500 | 135 | 135 | 100000/L80B10 | 3891 | 30.7 | 127 | 80+ | 4000 | 9.2 |
| Caelum A LED1x5300 G526 T840 OP | 1500 | 135 | 135 | 100000/L80B10 | 5295 | 40.9 | 129 | 80+ | 4000 | 9.2 |
| Caelum A LED1x5850 G527 T840 OP | 1500 | 135 | 135 | 100000/L80B10 | 5805 | 45.5 | 128 | 80+ | 4000 | 9.2 |
| Caelum A LED1x7050 G528 T840 OP | 1500 | 135 | 135 | 100000/L80B10 | 7914 | 54.1 | 146 | 80+ | 4000 | 9.2 |
Available options:
T830 – Colour temperature 3000K, CRI 80+
T840 – Colour temperature 4000K, CRI 80+
DALI – Driver with DALI interface and switch-control dimming
COR – Driver with Corridor function (never off)
COR1min – Driver with Corridor function 1 min (switch off after 1 min)
COR30min – Driver with Corridor function 30 min (switch off after 30 min)
*note – COR options not applicable for models: G514, G515
BLT – Integrated wireless control unit and driver for lighting control via mobile device (via Bluetooth), with integrated DALI PS
KRBLT – Integrated wireless control unit and driver for lighting control via mobile device (KR system app), on/off
KRBLT DALI – Integrated wireless control unit and driver for lighting control via mobile device (KR system app), DALI with integrated PS
MW – Integrated microwave (MW) motion sensor with on-off control
MWRFM+ – Integrated microwave (MW) motion sensor with integrated RF (radio wave) transceiver. Sensor can serve as both master and slave. Functions: Staircase, Corridor, dimming control
MW DALI2 – Integrated microwave (MW) motion sensor with DALI2 controls, requires power supply
MW KRBLT – Integrated wireless microwave (MW) motion sensor with KR system app control, on-off
MW KRBLT DALI – Integrated wireless microwave (MW) motion sensor with KR system app control and DALI power supply
*note – in outdoor environment frequently moving objects (e.g. trees, bushes, flags) can impact MW sensor operation
EM3 – Emergency version 3 hours
EM3A – Emergency version equipped with an autonomous testing system, 3 hours
EM3Atmin-25 – Emergency version equipped with an autonomous testing system, 3 hours. Suitable for low ambient temperatures up to -25 °C
EM3D – Emergency version 3 hours with DALI interface
*note – EM options applicable for models from 600 mm and longer
*note – Operating temperature range for luminaires with EM option, °C: 0…+35
5TB – 5-pole terminal block in middle of luminaire for easy through wiring
*note – 5TB terminal block included as standard
RAL – RAL colour
