| Name | Length, mm | Width, mm | Height, mm | LED lifetime, h | Output, lm | Power, W | Efficacy, lm/W | CRI (Ra) | CCT, K | Weight, kg |
| Disc B LED1x15000/12000/9000 J676 T840 | 265 | 265 | 158 | 85000/L80B10 | 9000/12000/15000 | 60/80/100 | 150 | 80+ | 4000 | 2.1 |
| Disc B LED1x22500/18000/13500 J677 T840 | 265 | 265 | 158 | 85000/L80B10 | 13500/18000/22500 | 90/120/150 | 150 | 80+ | 4000 | 2.1 |
| Disc B LED1x30000/24000/18000 J678 T840 | 300 | 300 | 160 | 85000/L80B10 | 18000/24000/30000 | 120/160/200 | 150 | 80+ | 4000 | 3.0 |
| Disc B LED1x15000/12000/9000 J676 T840 DIM ZHAGA18 | 265 | 265 | 158 | 85000/L80B10 | 9000/12000/15000 | 60/80/100 | 150 | 80+ | 4000 | 2.0 |
| Disc B LED1x22500/18000/13500 J677 T840 DIM ZHAGA18 | 265 | 265 | 158 | 85000/L80B10 | 13500/18000/22500 | 90/120/150 | 150 | 80+ | 4000 | 2.0 |
| Disc B LED1x30000/24000/18000 J678 T840 DIM ZHAGA18 | 300 | 300 | 160 | 85000/L80B10 | 18000/24000/30000 | 120/160/200 | 150 | 80+ | 4000 | 2.2 |
| Disc B LED1x15000 J676 T840 DALI | 265 | 265 | 158 | 85000/L80B10 | 15000 | 100 | 150 | 80+ | 4000 | 2.0 |
| Disc B LED1x22500 J677 T840 DALI | 265 | 265 | 158 | 85000/L80B10 | 22500 | 150 | 150 | 80+ | 4000 | 2.0 |
| Disc B LED1x30000 J678 T840 DALI | 300 | 300 | 160 | 85000/L80B10 | 30000 | 200 | 150 | 80+ | 4000 | 2.2 |
| Disc B LED1x15000/12000/9000 J676 T840 4EMG | 265 | 265 | 158 | 85000/L80B10 | 9000/12000/15000 | 60/80/100 | 150 | 80+ | 4000 | 2.0 |
| Disc B LED1x22500/18000/13500 J677 T840 4EMG | 265 | 265 | 158 | 85000/L80B10 | 13500/18000/22500 | 90/120/150 | 150 | 80+ | 4000 | 2.0 |
| Disc B LED1x30000/24000/18000 J678 T840 4EMG | 300 | 300 | 160 | 85000/L80B10 | 18000/24000/30000 | 120/160/200 | 150 | 80+ | 4000 | 2.2 |
Available options:
CBF3x1.5-N m – Outgoing flexible cable 3×1.5 mm², length according to customer specification
CBF4x1.5-N m – Outgoing flexible cable 4×1.5 mm², length according to customer specification
*note – please specify the length of outgoing cable before placing an order
Accessories:
Power supply connector – IP66/IP68, 3×1.5mm2 – Quick and easy to connect power supply and luminaire cable connector – IP66/IP68, 3×1.5 mm², 450V/10A, 1 pcs
Sensor HBPIR ZHAGA 360 D12/12 DIM B – PIR, Zhaga 18, 0-10V, IP65, 360°, d<12 m, h<12 m, black
Remote control RC-100 – Remote control unit
Disc B 4EMG kit – External emergency version 3 hours
*note – Disc B 4EMG kit available only for models Disc B LED 4EMG models
*note – operating temperature range for luminaires with Disc B 4EMG kit, °C: 0…+50
One-point High-bay Suspension MTG KIT, 1.5m – One-point high bay suspension kit for lifting eye type mounts, 1.5 meter
One-point High-bay Suspension MTG KIT, 3.0m – One-point high bay suspension kit for lifting eye type mounts, 3.0 meter
One-point High-bay Suspension MTG KIT, 5.0m – One-point high bay suspension kit for lifting eye type mounts, 5.0 meter
Sensor HBPIR ZHAGA 360 D20/12 DIM KRBLT B – PIR, Zhaga 18, 0-10V KRBLT, IP65, 360°, d<20 m, h<12 m, black
