| Name | Length, mm | Width, mm | Height, mm | LED lifetime, h | Output, lm | Power, W | Efficacy, lm/W | CRI (Ra) | CCT, K | Weight, kg | UGR index |
| Eridanus G LED1x750 J838 T840 WMC | 305 | 45 | 31 | 100000/L80B10 | 730 | 4.9 | 149 | 80+ | 4000 | 1.3 | ≤19 |
| Eridanus G LED1x900 J839 T840 WMC | 305 | 45 | 31 | 100000/L80B10 | 896 | 6.1 | 147 | 80+ | 4000 | 1.3 | ≤19 |
| Eridanus G LED1x1100 J840 T840 WMC | 305 | 45 | 31 | 100000/L80B10 | 1056 | 7.4 | 143 | 80+ | 4000 | 1.3 | ≤22 |
| Eridanus G LED1x2400 J886 T840 WMC | 305 | 45 | 31 | 100000/L80B10 | 2393 | 19.5 | 123 | 80+ | 4000 | 1.3 | |
| Eridanus G LED2x1x750 J841 T840 WMC | 305 | 45 | 31 | 100000/L80B10 | 1460 | 9.0 | 162 | 80+ | 4000 | 1.3 | ≤22 |
| Eridanus G LED2x1x900 J842 T840 WMC | 305 | 45 | 31 | 100000/L80B10 | 1792 | 11.1 | 161 | 80+ | 4000 | 1.3 | ≤22 |
| Eridanus G LED2x1x1100 J843 T840 WMC | 305 | 45 | 31 | 100000/L80B10 | 2111 | 13.4 | 158 | 80+ | 4000 | 1.3 | ≤22 |
| Eridanus G LED2x1x2400 J887 T840 WMC | 305 | 45 | 31 | 100000/L80B10 | 4787 | 37.0 | 129 | 80+ | 4000 | 1.3 |
Available options:
T830 – Colour temperature 3000K, CRI 80+
T840 – Colour temperature 4000K, CRI 80+
WGC – White gloss reflector with clear lens
BGC – Black gloss reflector with clear lens
WMC – White matt reflector with clear lens
BMC – Black matt reflector with clear lens
MGC – Metallic mirror finish reflector with clear lens
MMC – Metallic matt reflector with clear lens
WAC – Metallic mirror finish asymmetrical reflector with white shade and clear lens
BAC – Metallic mirror finish asymmetrical reflector with black shade and clear lens
*note – module quantities per model: J838…J840 – 1 pcs; J841…J843 – 2 pcs
DALI – Driver with DALI interface and switch-control dimming
EM3 – Emergency version 3 hours
EM3A – Emergency version equipped with an autonomous testing system, 3 hours
EM3D – Emergency version 3 hours with DALI interface
WIE3-0.5m – 3-pole “Wieland – gesis classic” type or compatible connector with 0.5 m cable
WIE5D-0.5m – 5-pole DALI “Wieland – gesis classic” type or compatible connector with 0.5 m cable
Europlug-1.5m – 2-pole “Europlug” type plug with 1.5 m cable
Europlug-3.0m – 2-pole “Europlug” type plug with 3.0 m cable
QBX2-0.1m – 2-pole quick connection box on 0.1 m cable, Push-in terminal, 2x2x2.5 mm2
CONCB/4 – Longer connecting cable for installing luminaires into every fourth ceiling tile
*note – CONCB/4 option is only available for models: J841…J843
